Description
The Makinex Generator Range is a robust, powerful, and reliable solution for providing power to equipment and tools, floor grinding, welders and brick saws., air compressors, and a wide range of applications.
They are suitable for use in rental yards, construction sites, and rural areas, and offer a compact lightweight option when moving the Generators around on building sites as well as on and off vehicles.
Reasons To Invest
- the most compact dual-phase Generator range in the market
- alternator allows you 11% more power from the engine
- fully Australian designed and made
- 1-year warranty
- the support you need, servicing, spare parts, on hand advice
- permanent magnet alternator technology reduces the cost of ownership.
Spec Sheets
| Rated output |
15000W |
| Max output |
16000W |
| Frequency |
60Hz |
| Voltage |
120V/240V + 240 3 phase |
| Sockets |
50amp 3-phase / 20amp single-phase / 30amp x 2 / 20amp |
| Weight |
342Ib (155kg) |
| Noise Level (7) |
No Load – 72dB
50% Load – 76dB
100% Load – 78dB |
| Engine |
GX-690 |
| Starting System |
Electric/Key Start |
| Engine Fuel Economy |
o.92gal @ 50% LOAD |
| Run Time |
10hrs @ 50% load |
| Dimensions |
30.4 in (L) x 20.8 in (W) x 35.5 in (H) |
| Frequency |
60Hz |
| Voltage |
120V/480V + 480 3 phase |
| Rated Output |
2500W (120V) / 12500W (480V) |
| Max Output |
2500W (120V) / 13500W (480V) |
| Sockets |
120V GFCI receptacle /
480V 3 phase receptacle (30 amp] |
| Weight |
342Ib (155kg) |
| Noise Level (7) |
No Load – 72dB
50% Load – 76dB
100% Load – 78dB |
| Engine |
GX-690 |
| Starting System |
Electric/Key Start |
| Engine Fuel Economy |
o.92gal @ 50% LOAD |
| Run Time |
10hrs @ 50% load |
| Dimensions |
30.4 in (L) x 20.8 in (W) x 35.5 in (H) |
Makinex Generators Product Data Sheet
Makinex Generator Comparison Guide
